1102-083-97-1

CONN 2.54mm Round Hole IC DIP Socket 08POS Press-Fit column pitch 7.62 contact plating sleeve Sn/clip Gold flash PBT Black UL94V-0

1102-XXX-XX-1

CONN 2.54mm Round Hole IC DIP Socket 08, 16, 24POS Press-Fit column pitch 7.62, 15.24 contact plating sleeve matte Sn/clip Au 0.38μm, Gold flash PBT Black UL94V-0

1121-021-97-1

CONN 2.54mm Single Row Round Hole DIP Socket 1X02POS Press-Fit Colloid height 3.00 contact plating sleeve Sn/clip Gold flash PPS Black UL94V-0

1121-XX1-97-1

CONN 2.54mm Single Row Round Hole DIP Socket 1×02 , 1x10POS Solder Colloid height 3.00 contact plating sleeve Sn/clip Gold flash PPS Black UL94V-0

1130-081-21-3

2.54mm Double Row Round Pin Header 2x04POS SMT+THT contact plating Gold flash LCP Black UL94V-0 with Specification A 7.30/B 1.50 Terminal diameter 0.64/1.20

1132-101-11-3

2.0mm Double Row Round Pin Header 2x05POS double side Solder Colloid Height 1.00 contact plating Gold flash LCP Black UL94V-0 with Specification A 3.70/B 0.30 Terminal diameter 0.50/1.00

1201-XX1-01-2

CONN Header 1x01, 1x02, 1×03, 1x04, 1x05, 1x06POS 2.54mm STACK Straight Solder single row single-plastic colloid Height 2.5 contact plating Gold flash PPS Black UL94V-0 with Specification A 11.6/B 3.2

1202-XX1-01-2

CONN Header 2x02,2×03,2x05,2x8,2x10,2x20POS 2.54mm STACK Straight Solder Double row single-plastic colloid Height 2.5 contact plating Gold flash PPS Black UL94V-0 with Specification A 11.6/B 3.2

1204-XX1-01-2

CONN Header 2x02, 2x03, 2×05, 2x13POS 2.54mm STACK Right Angle Solder Double row single-plastic colloid Height 2.5 contact plating Gold flash PPS Black UL94V-0 with Specification A 12.5/B 3.2/C 5.9

1204-XX4-06-3

CONN Header 2×02,2x04POS 2.54mm STACK Right angle Solder double row single-plastic colloid Height 2.5 contact plating Au0.25um Sn LCP Black with Specification A 10.35/B 3.0/C 3.5

1206-XXX-XX-X

CONN Header 2x03, 2×08, 2x13, 2x14, ..., 2x23POS 2.54mm STACK Straight Solder Double row double-plastic colloid Height 2.5 contact plating Au 0.38, Au0.76μm Sn PPS Black UL94V-0 with Specification A 26.0/B 3.0/C 16.5, A 14.5/B 2.4/C 6.3

1207-032-17-3

CONN Header 1×03POS 2.54mm STACK SMT single row single-plastic colloid Height 2.5 contact plating Au 0.38μm Sn LCP Black UL94V-0 with Specification A 9.65/B 5.84/C 5.0

1208-101-36-1

CONN Header 2X05POS 2.54mm STACK SMT double row single-plastic colloid Height 2.5 contact plating Au 0.38μm Sn LCP Black UL94V-0 with Specification A 10.00/B 5.80/C 7.50 with adsorption cap

1208-XX1-1X-1

CONN Header 2×05, 2x08POS 2.54mm STACK SMT double row single-plastic colloid Height 2.5 contact plating Au 0.38μm,Gold flash Sn LCP Black UL94V-0 with Specification A 9.80/B 5.80/C 7.50 with adsorption cap

1208-XX3-0X-3

CONN Header 2X02,2X10,2×13POS 2.54mm STACK SMT double row single-plastic colloid Height 2.5 contact plating Au 0.38μm Sn,Gold flash LCP Black UL94V-0 with Specification A 10.00/B 5.80/C 7.50 without positioning column with adsorption cap and Tape&Reel Packing

1211-145-AB-3

CONN Header 1X14POS 2.00mm STACK Straight Solder single row single-plastic colloid Height 2.0 contact plating Sn LCP Black UL94V-0 with Specification A 8.0/B 3.0 with adsorption cap(10.0*6.5) Tape&Reel Packing

1211-XXX-0X-3

CONN Header 1×02,1X03,1X04POS 2.00mm STACK Straight Solder single row single-plastic colloid Height 2.0 contact plating Au 0.076μm Sn LCP Black UL94V-0 with Specification A 8.0/B 2.5,A 8.8/B 2.8 without adsorption cap

1230-201-07-3

2.00mm Simple Ejector Header 2X10POS SMT colloid height 6.4 contact plating Au 0.38μm Sn LCP Black UL94V-0 with Specification A 7.6/B 3.60/C 5.3 without positioning column Tape&Reel Packing

1230-XX1-EX-3

2.00mm Simple Ejector Header 2×05~2x08,2X10,2X13,2X15,2X20POS SMT colloid height 6.4 contact plating Au 0.38μm, Au 0.76μm, Gold Flash Sn LCP Black UL94V-0 with Specification A 7.6/B 3.60/C 5.3 with positioning column Tape&Reel Packing

1230-XX9-1X-3

2.00mm Simple Ejector Header 2X03, 2×04, 2X05POS SMT colloid height 10.36 contact plating Au 0.38μm, Au 0.76μm Sn LCP Black UL94V-0 Fan connector with Specification A 11.60/B 4.15/C 7.6 with positioning column Tape&Reel Packing

1230122X

1230 series Simple Ejector Header housing assembly 2.00mm Female(wire terminal) 2x07~2x09,2x11~2x13POSPA66 Black UL94V-0 with left and right convex

12303016

1230 series Female Terminal wire Terminal Pitch 6.80mm phosphor bronze 1.27μm Ni under plated contact plating Au 0.38μm Fan connector

1235-XXX-XX-3

2.00mm Simple Ejector Header 1x06, 1×09POS single row Straight Solder Through hole colloid height 10.35 contact plating Au 0.38μm,Au 0.76μm Sn LCP Black UL94V-0 with specification A 12.65/B2.30/C6.95 with postioning column(one side)Tape&Reel Packing

1236-06B-GB-3

2.54mm Simple Ejector Header 2x03POS Straight Solder through hole colloid height 10.67*11.0 contact plating Sn LCP Black UL94V-0 fun connector with lower plate size 3.35 positioning column adsorption cap and Tape&Reel packing

1241-02X-01-3

CONN Header 1X02POS 5.08mm STACK Right Angle Solder single row U shape colloid Height 2.5 contact plating Gold flash LCP Black UL94V-0 with Specification A 33.00/B 5.84/C 1.5 , A 4.00/B 5.84/C 2.20

1261-406-A5-A

2.54mm Ejector Header with Ear Buckle 2x20POS Straight Solder contact plating Gold flash Sn PBT off-white UL94V-0 with Specification A 4.2/C 6.1 with Long ear buckle (B=8.2) lead with Round pin

1261-XXX-XX-X

2.54mm Ejector Header with Ear Buckle 2×08, 2×20, 2×30, 2×32POS Right Angle Solder contact plating Au 0.25, Au 0.38μm Sn, Gold Flash PA6T,High temperature nylon Black UL94V-0 with Specification A 4.2/C 6.1, A 3.7/C 5.8, A 3.2/C 5.8 with Long ear buckle (B=8.2) lead with square pin

12613010

1261 series Female Terminal wire Terminal Pitch 2.54mm phosphor bronze 1.27~2μm Ni under plated contact area Gold flash

1262-200-22-1

2.54mm Receptacle 2X10POS Double Row Straight Solder colloid height 8.5 contact plating Gold flash Sn PBT Black UL94V-0 with shrapnel lower plate size 3.0

1262-XX1-XX-1

CONN Receptacle 2×13, 2x16POS 2.54mm Straight Solder double row colloid height 8.5 contact plating Au 0.38μm, Au 0.76μm Sn PBT Black UL94V-0 with lower plate size 3.00

1268-XX2-2X-3

CONN Receptacle 2×02~ 2x16POS 2.54mm SMT shrapnel double row colloid height 4.57 contact plating Au 0.25, Au 0.38, Au 0.76μm, Gold Flash Sn LCP Black UL94V-0 with Specification A 4.75/B 6.35

1271-XX1-2X-1

CONN Receptacle 2×08POS 2.54mm Straight Solder shrapnel double row colloid height 7.37 contact plating Au 0.38μm Sn PBT Black UL94V-0 with Lower plate size 3.0

1280-000-12-1

CONN 2.54mm short circuit common closure contact plating Gold flash PBT Black UL94V-0

1280-000-21-9

CONN 2.00mm short circuit common closure contact plating Gold flash PBT Blue

1280-001-12-X

CONN 2.54mm short circuit common closure contact plating Gold flash PBT Black，Blue UL94V-0

1296-252-42-3

CONN Receptacle 2x25POS 2.00mm SMT Shrapnel double row colloid height 4.30 contact plating Au 0.25μm LCP Black UL94V-0 with Specification A 6.00/B 4.60

1296-XX2-4X-3

CONN Receptacle 2x05,2x25POS 2.00mm SMT shrapnel double row colloid height 4.30 contact plating Au 0.38μm Sn LCP Black UL94V-0 with Specification A 6.00/B 4.60

1296-XX2-XX-3

CONN Receptacle 04,06,14,25,48+5POS 2.00mm SMT shrapnel double row colloid height 4.30 contact plating Gold flash,Au 0.25μm ，Au 0.38μm, Au 0.76μm LCP Black UL94V-0 with Specification A 6.00/B 4.60

1303-063-1B-3

2.50mm Wafer(Round pin) Right Angle 06P Type 3(oval window Straight male PIP) Contact plating Sn LCP Black Tape&Reel packing Fan Wafer Connector with Lower plate Size 2.80

1341-065-1B-N

1.25mm Wafer Connector 06P Type 5 Straight SMT contact plating Sn LCP Natural UL94V-0

1341-XX7-X7-3

1.25mm Wafer Connector 2×10, 2x15, 2x20P Type 7(without horns) Straight SMT contact plating Au 0.38μm Sn LCP Black UL94V-0

1341-XXX-XB-N

1.25mm Wafer Connector 02~15P Type 2(Width 3.3) Straight SMT contact plating Sn LCP Natural UL94V-0

1342-XXX-1B-N

1.50mm Wafer Connector 02,03,04,05,06P Type1(vertical Mount SMT)contact plating Sn LCP Natural UL94V-0 with the adsorption cap

1343-061-1B-N

2.50mm Wafer Connector 06P Straight male Solder Contact plating Sn LCP Natural UL94V-0 with lower plate size 3.3

1343-XXX-1B-X

2.50mm Wafer Connector 08P Right Angle male Solder Contact plating Sn LCP,PA66 Natural UL94V-0 without corner bayonet facing down lower plate Size 3.3

1344-021-2B-P

3.96mm Wafer Connector 02P Straight male Solder Contact plating Sn PA6T Natural UL94V-0 with Lower plate Size A 3.7/B 14.6

1344-XXX-XB-D

3.96mm Wafer Connector 02~12P Straight male Solder Contact plating Sn PA66 Natural UL94V-0 Specification A 3.7/B 14.6, A 3.3/B 12.3, A 6.5/B 17.4

1346-241-7B-N

2.00mm Wafer Connector 2 x 12P Type 5（with latch）Double Row Straight male Solder Through Hole Contact plating Sn LCP Natural UL94V-0 with Stand-off0.80 with adsorption cap

13463009

1346 series Wafer Female terminal Double Row wire Terminal Phosphor bronze contact plate Sn

1348-040-DB-N

4.20mm Wafer Connector 2x02P double row Straight male Solder without positioned column contact plating Sn LCP Natural UL94V-0 with hollow male pin and lower plate size 3.5

1348-XX0-XX-X

4.20mm Wafer Connector 2×04, 2x07P double row Straight male Solder contact plating Sn LCP Natural UL94V-0 without positioning column with hollow male pin and lower plate size 3.0, 3.5

1348-XXX-XX-X

4.20mm Wafer Connector 2×01, 2x02, 2x04, ..., 2x12P double row Straight, Right Angle male Solder through hole contact plating Sn LCP Black UL94V-0 with or wihtout positioning column lower plate size 3.2，3.5， 5.3， 6.3

1349-144-FB-3

3.00mm Wafer(Male Terminal）connector 2 x 07P Double Row Straight Solder Through Hole Contact plating Sn LCP Black UL94V-0 with positioning column foot length 2.8

1349-XXX-XB-3

3.00mm Wafer Connector 2×02, 2x03, 2x04, 2x06,2x07, 2x10P(Male Terminal）double row Straight ,Right Angle Solder contact plating Sn LCP Black UL94V-0 with or without positioned column foot length 3.18,3.3, 3.5 with Harpoon Terminal with K

13493001

1349 series MF3.0 Wafer Female Terminal shrapnel type crimping 1.27 ~2 μm Ni under plated outer plating Sn 3~5μm 18~26 AWg

1403-152-N5-1

CONN D-SUB high density Receptacle 15POS female Solder Cup Contact plating Gold flash Sn PBT Black UL94V-0 Front and rear shell salt spray 24H with rear square rivet nut 14055002/14055003

1405-091-05-1

CONN D-SUB standard plug 09POS male Solder Cup Contact plating Gold flash Sn PBT Black UL94V-0 without matching hardware/Round hole 3.05

1405-092-05-1

CONN D-SUB standard Receptacle 09POS female Solder Cup Contact plating Gold flash Sn PBT Black UL94V-0 without matching hardware/Round hole 3.05

1406-158-B5-R

CONN D-SUB high density PCB Receptacle 15POS Right Angle Solder Contact plating Gold flash Sn PA9T Blue UL94V-0 with Super short type Front screw/rear gasket + harpoon

1406-XXX-XX-X

CONN D-SUB high density PCB Receptacle Right Angle 15,26,44,78POS Solder Contact plating Gold flash Sn PBT Black UL94V-0 ultrashort type without screw hole+harpoon

1408-094-15-1

CONN D-SUB standard PCB Receptacle Right Angle 09POS Solder contact plating Gold flash Sn PBT Black UL94V-0 Front shell salt spray 24H economy terminal front nut/rear gasket + harpoon

1450-155-07-1

CONN D-SUB high density QDB PCB plug Right Angle 15POS Press-FIT contact plating Au 0.38μm Sn PBT Black UL94V-0 Integral salt spray 48H without shield shell

1809-424-0F-N

2.00mm Bend male connector 4x24POS Press-Fit contact plating Au 0.76μm OR PdNi0.76μm+Gold flash Sn LCP Natural UL94V-0 with standard structure

1870-361-H8-3

CONN Mini SAS 0.8mm Pitch 36POS Straight SMT Internal interface Contact plating Au 0.76μm Sn LCP Black UL94V-0 shielding shell without buckle/solder plate/lower plate size 3.18

1877-07C-58-3

CONN SATA 1.27mm Plug 07POS Straight Solder Contact Plating Au 0.76μm Sn LCP Black UL94V-0 with Type B all-inclusive slotted pin length 2.50 with harpoon

1883-293-48-3

CONN SAS Male Header 29POS Right Angle SMT Contact Plating Au 0.76μm Sn LCP Black UL94V-0 with Sinker plate Type Sink plate depth 2.5 with ground lug

1884-288-38-8

DDR4 DIMM 288POS SMT Solder positioning plating Au 0.76μm black hard TRAY with Mylar

1887-520-71-3

CONN MIni PCI-E Pitch 0.80mm Receptacle 52POS SMT Contact Plating Gold flash LCP Black UL94V-0 surface-mount with H=7.0
